RightTemp® Sensor for Animal or Warming Pad
For use with the RightTemp® module, available in the SomnoSuite®, PhysioSuite®, CODA®, and RoVent Jr.® systems.
This sensor is for all new systems and existing systems with serial numbers ending in “-B.”
Specifications
| Resistance: | 2,255 ohms |
| Tolerance: | +/-0.2°C |
| Accuracy: | 25°C to 45°C |
| Operating Temperature: | -40°C to 80°C |
| Sensor Diameter: |
Ball Tip Diameter: 1.65 mm max Shaft: 1.5 mm |
| Time Constant: | 10.0 seconds |
